Application

Hazardous area

Markets
Oil & Gas
Key Specifications
Certifications
ONVIF CONFORMANT PRODUCT
ATEX CERTIFICATION
IECEX CERTIFICATION
UKCA CERTIFICATION
INMETRO CERTIFICATION
ECAS EX CERTIFICATION
FM CERTIFICATION
Description

TXPDTV2-TIxx / TXPUSDTV2-TIxx is an ATEX/IECEX/UKCA/INMETRO/ECAS EX/CLASS-DIV certified DUAL VISIBLE & THERMAL PTZ camera station, entirely made in electro-polished AISI316L stainless-steel, specifically designed for Hazardous Area applications. It is equipped with the latest generation 5MP IP day/night camera and an extremely sensitive thermal camera that ensures simultaneous video surveillance even in total darkness, as well as a sunshields, heaters/demisters and wiper (for the visible camera). It delivers multi stream H264/H265/MJPEG encoding, it is ONVIF compliant and compatible with most VMS available in the market. Fiber optic media converter, IP over the coaxial and PSU can be integrated upon request. It's also available in GRIDLESS version (patented).

The "NEXT" series makes use of the latest technologies and it's a great video surveillance solution for potentially explosive applications such as Oil & Gas exploration/extraction, Oil & Gas refining/transport, and for installations in the most severe environments either onshore or offshore.

Features
  • INNOVATIVE PRODUCT, BEST IN CLASS TECHNOLOGY
  • ATEX/IECEX/UKCA/INMETRO/ECAS EX/CLASS-DIV EXPLOSIONPROOF PTZ FOR HAZARDOUS LOCATIONS
  • AISI316L STAINLESS STEEL CONSTRUCTION
  • CERTIFICATION TEMPERATURE -60°C +80°C
  • VISIBLE: 5MP, H.265, 40x AUTOFOCUS OPTICAL ZOOM
  • THERMAL: 640x512 RESOLUTION, 9HZ OR 30HZ, LWIR
  • DUAL INDEPENDENT VISIBLE AND THERMAL VIDEO STREAMS
  • WIDE RANGE OF THERMAL LENSES
  • ADVANCED PREINSTALLED VIDEO ANALYTICS
  • EIS ELECTRONIC IMAGE STABILIZER (VISIBLE)
  • INTEGRATED WINDOW WIPER (VISIBLE)
  • VERY LOW POWER CONSUMPTION
  • EASY MAINTENANCE
  • IP66/67/68/69, NEMA 4X
  • OPTIONAL BUILT-IN FIBER MEDIA CONVERTER
  • OPTIONAL BUILT-IN 120VAC OR 230VAC POWER SUPPLY
  • H2-READY
